Aluminum Radiator ER-500/100AL

Aluminium Radiator EPA ER-500/100AL (10 sections)

This is a sectional aluminium radiator for water heating systems. The set has 10 sections, each with a heat output of 150 W, so the 10 sections together give about 1500 W. The centre distance is 500 mm. The section depth is 100 mm. The working pressure is 12–18 bar, the test pressure 20 bar and the maximum pressure 36 bar.

Advantages

• Aluminium body — light and a good heat conductor, so it warms up and heats the room quickly
• Sectional design — you can add or remove sections to suit the size of the room
• 500 mm centre distance — the most common standard size, so connection points match when replacing an old radiator
• Working pressure of 12–18 bar and maximum pressure of 36 bar — suitable for central and stand-alone heating systems

Application

Used in water heating systems in flats, offices and commercial buildings, and especially well suited to stand-alone (boiler) systems. Choose the number of sections to suit the room's floor area and the heat output you need.

Note on use

The radiator should be installed by a qualified plumber. Bleed the air from the radiator after filling the system. Do not leave the heating system without water for long; with hard water, fitting a mains filter is recommended.

EPA ER-500/100AL — a light aluminium radiator that gives off heat quickly and evenly.
