Bimetal Radiator ER-500/80BM

Bimetallic Radiator EPA ER-500/80BM (10 sections)

This is a sectional bimetallic radiator with steel inner water channels and an aluminium outer body for water heating systems. The set has 10 sections, each with a heat output of 113 W, so the 10 sections together give about 1130 W. The centre distance is 500 mm. The section depth is 80 mm. The working pressure is 12–18 bar, the test pressure 20 bar and the maximum pressure 51 bar.

Advantages

• Bimetallic design — the steel core handles high pressure and water hammer, while the aluminium body gives off heat quickly
• Sectional design — you can add or remove sections to suit the size of the room
• 500 mm centre distance — the most common standard size, so connection points match when replacing an old radiator
• Working pressure of 12–18 bar and maximum pressure of 51 bar — suitable for central and stand-alone heating systems

Application

Used in water heating systems in flats, offices and commercial buildings. Its high pressure rating makes it especially suitable for central heating in apartment blocks. Choose the number of sections to suit the room's floor area and the heat output you need.

Note on use

The radiator should be installed by a qualified plumber. Bleed the air from the radiator after filling the system. Do not leave the heating system without water for long; with hard water, fitting a mains filter is recommended.

EPA ER-500/80BM — a bimetallic radiator that withstands high pressure and gives off heat evenly.
